Medical monitor support arm / wall-mounted SMB A100 ITI TECHNOLOGY

Medical monitor support arm / wall-mounted SMB A100 ITI TECHNOLOGY
SMB A100


- Up/Down vertically (up 43° & down 43°) and left/right rotation (90~360° adjustable) - Display mounting bracket features tilt, rotation, pivot and swivel adjustments - Pull down/up the display for the desired viewing position - Easy installation in areas where space or interference (Wall,Ceiling, Floor, Bed frame and Cabinet) - Minimize the bedside space - Cables (coaxial, power, cat5/6, remote control wire) management through the arm - Display Extension: 80 ~ 150cm (including wall extension arm over 80cm) - Display Arm Up and Down: 86º - Display Cable Management: Internal - Color Option: RAL9010 glossy (or option) - Wall bracket type 650 - Weight capacity 2kg ~ 18kg - VESA 75mm and 100mm plate - Shipping Weight: 8 kg (net 7.2 kg) including Arm + display mounting extension + mounting bracket - Shipping Dimension: 100 x 36 x 12cm
  • Applications: : medical
  • Configuration: : wall-mounted
******
